Agilent 34401A Digital Multimeter 6½ Digit. Power On, Tested 30-Day Free Returns
Used, working, very good condition as shown in pictures. 30-Day Free Returns No Questions Asked! If you need more photos or information, please contact us.
DC voltage
Measurement method Continuously integrating multi-slope III A-D converter
A-D linearity 0.0002% of reading + 0.0001% of range
Input resistance
10 MΩ or 0.1V, 1 V, 10 V ranges Selectable > 10,000 MΩ
100 V, 1000 V ranges 10 MΩ ± 1%
Input bias current < 30 pA at 25 °C
Input protection 1000 V all ranges
True RMS AC voltage
Measurement method AC-coupled true rms-measures the AC component of the input with
up to 400 Vdc of bias on any range
Crest factor Maximum of 5:1 at full scale
Input impedance 1 MΩ ± 2% in parallel with 100 pF
Input protection 750 Vrms all ranges
DC current
Shunt resistance 5 Ω for 10 mA, 100 mA
0.1 Ω for 1 A, 3 A
Input protection Externally accessible 3 A 250 V fuse
Internal 7 A 250 V fuse
True RMS AC current
Measurement method Directly coupled to the fuse and shunt. AC coupled true RMS
measurement (measures the AC component only).
Shunt resistance 0.1 Ω for 1 A and 3 A ranges
Input protection Externally accessible 3 A 250 V fuse
Internal 7 A 250 V fuse
